Highleap is a professional and reliable one-stop PCB solutions provider for customers.HighLeap is responsible for overseas business development.With high quality and on-time delivery products we won the market's wide acclaim. We will continue to focus on customer satisfaction, along with "high quality “and "fast delivery", we will become a PCB service provider worthy of customer trust.
Our products include pcb,pcb assembly,components,Keyboard pcb design,Rigid-Flex PCB,FPC.,etc. To meet customers' various demand. Our products are widely used in communication, medical equipment, industrial control, power supply, consumer electronics and aerospace, automobile industry,etc.All our products follow IPC class and are approved by UL, ROHS and ISO9001. Also our executives and technicians are experienced people who have been engaged in PCB industry for more than twenty years so we have rich production management experience and professional PCB skills.
We ensure the quality of PCB products by continuously introducing new equipment’s and new technologies and using high quality materials .With professional technicians we can provide early design consultation and technical support, so that customers can be more worry-free. With qualified and reliable products, advanced technology and value-added service, we won the trusts and supports of customers and established a good reputation in the industry.Our goal is to be the leading PCB solutions provider in the electronics industry with first-class products and services. We are devoted to be a trusted partner of our customers.
HighLeap PCBA.Our products have been committed to production efficiency and production standardization. Now PCBA production has achieved more than 50% automatic production, and the machine production pass rate is 99%. The production speed has also been greatly improved. We use manual and machine testing methods to make the products shipped are 100% qualified.
Item
(pcb manufacturer)
Capability
(pcb,Flexible pcb,Rigid-flexible pcb)
Base Material
FR-4 / High TG FR-4 / Halogen Free material/Rogers/Arlon/Taconic/Teflon
Layers
1-22
Finised inner/outer copper thickness
1-6OZ
Finished board thickness
0.2-7.0mm
Min hole size
Mechanical hole: 0.15mm
Laser hole: 0.1mm
Controlled Impedance
+/-5%
Plugging vias capability
0.2-0.8mm
Outline profile
Rout/ V-cut/ Bridge/ Stamp hole
Surface treatment
HASL, HASL lead free, Immersion Gold, Immersion Tin, Immersion Silver, Hard gold, Flash gold, OSP…
Our products have always been committed to production efficiency and production standardization.
We have a complete production line, PCB, flex pcb, rigid-flex pcb is one of the main production items of our company, we have sufficient raw materials, advanced equipment, rich production experience, fast and rigorous production process, plus we A strong technical team can also provide design and professional help.
Production Line:
HighLeap PCB production is simply divided into the above 12 steps, Sheet cutting, Lamination, Drilling, Inner/Outer Imaging, surface treatment, Solder Mask, AOI, Plating, Legend, E-testing/TDR, Profiling, FQC.
We have a complete production line, sufficient raw materials, advanced equipment, rich production experience, professional staff, and fast and rigorous production processes.
HighLeap PCBA.The 12 steps in the PCBA picture are divided into two types: SMT and DPI. SMT1, SMT2, SMT3, SMT4, SMT5, SMT6, Automatic optical inspection is the main production machine, which makes printing solder paste, SPI, SMD, soldering the whole The process is fully automated. After the welding is completed, there will be an AOI performance test to ensure that there is no problem with the product. There is no problem with the finished product Washing board and FQC and the PCBA processing is completed.Then we will arrange staff to wash the board and FQC qualified products.
R&D:
Custom Keyboard PCB R&D supported
PCB
40%
50%
60%
65%
75%
80%/TKL
95%
100%
Standard
/
/
ISO、ANSI
keys
41
51
61
68
80
87
95
104
Color of PCB
Green、Black 、Orange、Blue、Customized
Connector
Type C、USB、Micro USB
Material
Fr4/Customized
Function
Hot swapple、Blue-tooth、Wireless/Wired、RGB、Customized
Switch
3 pin/5 pin
Program
QMK/Via support
Logo
Customized
Assembly
Accept
Gerber file
Customized
Bom list
Customized
R&D Team Keyboard PCB Industry
Our HighLeap Keyboard Pcb team was founded in Guangzhou, China. We have more than 20 years of experience in the mechanical keyboard industry. Being professional and proficient in mechanical keyboard manufacturing, R&D, and being familiar with the needs of customers and the market, we are confident to deliver a quality experience with innovative mechanical keyboard products.
We continue to invest in advanced production facilities to connect our equipment, people and processes. This will finally help us improve productivity, quality, responsiveness, as well as the accuracy of decision making throughout the product lifestyle.
The deep in-house machining capability of these professionals streamlines the manufacturing process and provides our customers with the best product, faster and with less risk.
Our Team:
HighLeap Team with more than 20+ oversea sales,Experience with PCB,PCB Assembly,Keyboard PCB,IC And Components supported.
HighLeap'Team annual international exhibition attracts old and new customers
from Europe, America,Asia,Oceania,Africa and so on.
During their visit, they highly appraise our products and praiseour customer-centered,
